D25 HF Smart Label – The Resistance
This D25 label is specially designed to increase its protection level for better resistibility against water and the environment stress. Meanwhile, the label body is enhanced in thickness for greater robustness. It ideally goes to clothing in daily wash.
Play Video
Specifications
| Die Cut Size | 25phi | |||||||||||||||
| Antenna Size | 21phi | |||||||||||||||
| Material | synthetic paper / art paper/ PET | |||||||||||||||
| Frequency | HF | |||||||||||||||
| Operating Temperature (°C) | -25 to 70 | |||||||||||||||
| Storage Temperature (°C) | -25 to 70 | |||||||||||||||
| Applicable Surface | Non-metal | |||||||||||||||
| RFID Chip | NXP NTAG213 | |||||||||||||||
| NFC Standard | Type 2 | |||||||||||||||
| RF Interface Protocol | ISO/IEC 14443A | |||||||||||||||
| Options | preprinted artwork, thermal transfer for QR code/ Barcode/ UID printing |
